1MB Siemens 6ES7412-5HK06-0AB0 CPU412-5H PN DP Central Processing Unit
| Place of Origin | Germany |
| Brand Name | SIEMENS |
| Certification | ROHS |
| Model Number | 6ES7412-5HK06-0AB0 |
1MB siemens 6es7412 5hk06 0ab0
,DP siemens 6es7412 5hk06 0ab0
,6ES7412-5HK06-0AB0 Processing Unit
6ES7412-5HK06-0AB0 CPU412-5H PN/DP, 1MB F. S7-400H/F/FH
| Product type designation | CPU 412-5H PN/DP |
|---|---|
| HW functional status | 1 |
| Firmware version | V6.0 |
- Isochronous mode: No
- Engineering with Programming package: As of STEP 7 V5.5 SP2 with HF1
- CiR - Configuration in RUN
- CiR synchronization time, basic load: 100 ms
- CiR synchronization time, time per I/O byte: 0 µs
| Supply voltage | Power supply via system power supply |
|---|---|
| Input current from backplane bus (5V DC) | Typ. 1.6 A / Max. 1.9 A |
| Input current from backplane bus (24V DC) | Max. 150 mA; 150 mA per DP interface |
| Power loss | Typ. 7.5 W |
| Type of memory | RAM |
|---|---|
| Work memory (integrated) | 1 Mbyte (512 kbyte for program, 512 kbyte for data) |
| Load memory | Expandable FEPROM: Yes (max. 64 Mbyte) Integrated RAM: max. 512 kbyte Expandable RAM: Yes (max. 64 Mbyte) |
| Backup | Present: Yes With battery: Yes (all data) Without battery: No |
|---|---|
| Backup battery | Backup current: Typ. 180 µA (valid up to 40°C), Max. 1 000 µA Backup time: See module data manual External backup voltage: 5 V DC to 15 V DC |
- Bit operations: 31.25 ns (typ.)
- Word operations: 31.25 ns (typ.)
- Fixed point arithmetic: 31.25 ns (typ.)
- Floating point arithmetic: 62.5 ns (typ.)
- DB Number: Max. 6,000 (Range: 1 to 16000)
- DB Size: Max. 64 kbyte
