BENTLY NEVADA 330750-40-05 High Temperature Velomitor System made in USA
|
BENTLY NEVADA 330750-40-05 High Temperature Velomitor System made in USA
| Place of Origin | USA |
| Brand Name | BENTLY NEVADA |
| Certification | ROHS |
| Model Number | 330750-40-05 |
Product Details
Communication Protocol:
Ethernet, Modbus, OPC, Profibus, HART
Cable:
Standard Cable
System Length:
7.0 Metres (23.0 Feet)
Probe Case Type:
M30x2 Thread
Diameter:
5mm
Estimated Lead Time:
8 - 10 Weeks
Probe Penetration:
21 Mm
Model Type:
System Rack
Certifications:
CE, ATEX, FM, CSA, IECEx
Accuracy:
Vibration: ± 1%, Position: ± 0.1 Mm, Temperature: ± 1°C, Pressure: ± 0.5% Of Full Scale, Speed: ± 0.1% Of Full Scale, Process Variables: Customizable
Mounting Base:
Circular; 1/4-in 20 UNC Stud
Standoff Adapter:
No Standoff Adapter
Mounting Thread:
M8 X 1 Integral Stud
Operating Temperature:
-40 To 70°C
Highlight:
Bently Nevada Velomitor System
,High Temperature Velomitor System
,GE Bently Nevada vibration monitoring
Payment & Shipping Terms
Minimum Order Quantity
1PC
Price
US$1099
Packaging Details
factory original
Delivery Time
4-6days
Payment Terms
T/T
Supply Ability
50PCS/MONTH
Product Description
BENTLY NEVADA 330750-40-05 High Temperature Velomitor System
The 330750 and 330752 High Temperature Velomitor System sensor head and integral cable are designed for high temperature environments, enabling mounting on surfaces with temperatures up to +400°C (+752°F).
Technical Specifications
| Parameter | Value |
|---|---|
| Electrical Sensitivity | 5.7 mV/mm/s (145 mV/in/s) ±5% |
| Frequency Response | 15 to 2000 Hz (900 to 120,000 cpm) ± 3.0 dB; 20 to 1000 Hz (1,200 to 60,000 cpm) ± 0.9 dB |
| Transient Temperature Sensitivity | 0.0762 mm/s/°C (0.003 in/s/°C), typical |
| Amplitude Range | 635 mm/s (25 in/s) peak below 680 Hz. 2940 m/s2 (300 g) peak above 680 Hz |
| Transverse Sensitivity | Less than 5% of Sensitivity |
| Mounted Resonant Frequency | Greater than 5 kHz |
| Output Bias Voltage | -12 ±2.0 VDC |
| Maximum Cable Length | 305 meters (1000 feet) with no degradation of signal |
Environmental Limits
| Component | Temperature Range |
|---|---|
| Sensing Head | -55°C to +400°C (-67°F to +752°F) |
| Integral Hardline Cable | -55°C to +400°C (-67°F to +752°F) |
| Electronics | -55°C to +121°C (-67°F to +250°F) |
Product Overview
These sensors monitor casing vibration of large and medium-sized rotating machinery including steam turbines, water turbines, fans, compressors, and more. Widely applied in electric power, petroleum, chemical, and metallurgy industries.
