VEGA WE61.GXANDRAMX VEGAWAVE 61 Vibrating level switch for powders

For powdery and fine-grained bulk solids from density 8 g/l - compact version

Detects the limit level reliably with millimeter accuracy directly at the mounting position. The tuning fork design is robust and unaffected by buildup. Maximum grain size: 10 mm.

The VEGAWAVE 61 is a level switch for universal use in powders and fine-grained bulk solids. It reliably detects minimum or maximum limit levels. Ideal for adhesive, abrasive products, and bulk solids with very low density.

• Low maintenance costs due to robust design
• Quick setup without medium reduces time and cost expenditure
• Reliable function with product-independent switching point

• Version/Process temperature: Standard / -50...+150°C
• Process fitting/Material: Thread 1½NPT PN25, ASME B1.20.1 / 316L
• Electronics: Relay (DPDT) 20...72 V DC/20...253 V AC (3A)
• Housing/Protection: Aluminium single chamber / IP66/IP67
• Special color: None
• Switching point: Standard sensitivity (from density 0.02 g/cm³)
• Mode: Overflow protection

• Suitable for tropical regions with all metal attachment parts
• Dye penetration test included with inspection certificate
• SIL qualification included with Safety Manual
• High voltage test included with inspection certificate
• Low temperature test (-60°C) included with inspection certificate
• Durability test (360h) included with inspection certificate
• Customs tariff number (HS code): 90318080
