Yokogawa EJA Pressure Transmitter
>
Differential Yokogawa EJA Pressure Transmitter Draft Range EJA120E-JES5G-934DJ
|
Differential Yokogawa EJA Pressure Transmitter Draft Range EJA120E-JES5G-934DJ
| Place of Origin | JAPAN |
| Brand Name | YOKOGAWA |
| Certification | ROHS |
| Model Number | EJA120E-JES5G-934DJ/KU22/M01/D4/N4 |
Product Details
Model:
EJA120E-JES5G-934DJ/KU22/M01/D4/N4
Manufacturer:
Yokogawa
Accuracy::
± 0.2% Accuracy (0.09% Available With /HAC Option)
Product Name:
Draft Range Differential Pressure Transmitter
Design:
True Draft Range Design
Response Time:
150 Ms
Stability:
± 0.3% Per 1 Year Stability
Certificate:
Exida And TUV SIL 2/3 Certified
Packing:
Standard Yokogawa Carton
Highlight:
Differential Yokogawa EJA Pressure Transmitter
,EJA120E Yokogawa EJA Pressure Transmitter
,Yokogawa EJA130E Transmitter
Payment & Shipping Terms
Minimum Order Quantity
1PC
Price
negotiable
Packaging Details
factory original
Delivery Time
8-10weeks
Payment Terms
T/T
Supply Ability
50PCS/MONTH
Product Description
Differential Yokogawa EJA Pressure Transmitter Draft Range EJA120E-JES5G-934DJ
EJA120E-JES5G-934DJ EJA120E Draft Range Differential Pressure Transmitter
Product Specifications
| Manufacturer | Yokogawa |
|---|---|
| Product No. | EJA120E-JES5G-934DJ |
| Product Type | Differential Pressure Transmitter |
| Output Signal | 4 to 20 mA DC with digital communication (HART 5/HART 7 protocol) |
| Measurement span (capsule) | 0.1 to 1 kPa (0.4 to 4 inH2O) |
| Wetted parts material | ASTM CF-8M |
| Capsule | Hastelloy C-276 *2 (Diaphragm) F316L SST, 316L SST (Others) |
| Capsule gasket | PTFE Teflon |
| Vent/Drain plug | 316 SST |
| Bolts and nuts material | 316L SST |
| Integral indicator | Digital indicator |
| Weight | 3.7 Kg |
| Shipping Weight | 8 Kg |
The EJA120E is the traditional-mount Draft Range Pressure Transmitter in this series.
Key Features
- ± 0.2% Accuracy (0.09% available with /HAC option)
- ± 0.3% per 1 year Stability
- 150 ms Response Time
- Exida and TUV SIL 2/3 Certified
- Local Parameter Setting (LPS)
- True Draft Range design
Available with HART 5/7, 1 to 5 VDC HART 7 (Low Power), FOUNDATION Fieldbus, PROFIBUS PA, or BRAIN communication.
